ENTRELEC HDM609 DIN terminal block screw 0.5-10mm² gray

ENTRELEC HDM609 DIN terminal block screw 0.5-10mm² gray

ENTRELEC
1,46 €
AR PVN
ENTRELEC HDM609 DIN screw terminal block, 0.5-10 mm² conductor range, 57A rated, 1000V, 2-position, thermoplastic insulation.
Pēc pasūtījuma
Share

Paziņot kad ir pieejams

Interested in this product? Drop us an email and we will let you know when it's available for order.

ENTRELEC HDM609 DIN rail screw terminal block for flexible conductor routing. Thermoplastic insulation housing with dual positions and robust screw connections suitable for industrial applications.

  • Conductor range 0.5-10 mm² (fine and solid)
  • 57 A nominal current rating
  • 1000 V nominal voltage
  • 2-position terminal block
  • 35 mm DIN rail mounting
  • Screw connection type
  • Thermoplastic housing material
  • Operating range -40°C to +110°C
  • Explosion-proof Ex e version available

  • Zīmols
  • Norāde
    HDM609
  • ean13
    3472595080106
  • MPN
    HDM609

  • Operating temperature
    -40 to 110 °C
  • Montāža
    55 mm DIN rail
  • Pieslēgums
    Screw terminal
  • Nominal voltage
    1000 V
  • Nominal Current
    57 A
  • Positions per level
    2
  • Conductor range (fine bare)
    0.5-10 mm²
  • Conductor range (fine with ferrule)
    0.5-6 mm²
  • Conductor range (solid)
    0.5-10 mm²
  • Conductor range (stranded)
    0.5-4 mm²
  • Levels
    1
  • Insulation body material
    Thermoplastic
  • Explosion-proof version (Ex e)
    Yes
