VidiLine VIDI-AC-2CS-P Flush Mount Access Control Keypad with Card Reader

VidiLine VIDI-AC-2CS-P Flush Mount Access Control Keypad with Card Reader

VidiLine
34,93 €
Maksudega
IP66-rated flush mount access control keypad with card reader. Supports 1000 users, PIN/card access, Wiegand. Ideal for outdoor use.
Delivery: 5 business days
Jaga

The VidiLine VIDI-AC-2CS-P is a versatile flush mount access control keypad with an integrated 125kHz EM card reader. Designed for both indoor and outdoor use, it features an IP66 weatherproof rating and a stainless steel housing for durability in harsh conditions.

  • IP66 weatherproof – dust-tight and protected against powerful water jets
  • Supports up to 1000 users (990 normal + 10 guests) with PIN, card, or card+PIN access
  • 12-key backlit keypad with 4~6 digit PIN codes
  • 125kHz EM card reader with up to 6cm read range
  • Wiegand 26-bit output and 26/34-bit input with auto-detection
  • One relay (NO/NC/COM) rated up to 2A, with adjustable hold time (0-99 seconds)
  • Tamper alarm for added security
  • Wide operating temperature from -40°C to 60°C

This controller is ideal for securing single doors in residential or commercial settings. The package includes the device, mounting hardware, and a diode for relay protection.

  • Bränd
  • Tootekood
    VIDI-AC-2CS-P
  • Laosolevad enne
    999 Tooted
  • MPN
    VIDI-AC-2CS-P

  • IP rating
    IP66
  • Power supply
    12~18V DC
  • Installation
    Flush mount
  • Dimensions
    2~6 cm
  • Operating temperature
    -40~60 °C
  • Weight
    Not specified
  • Housing material
    Stainless steel
  • Operating humidity
    up to 98% non-condensing
  • User capacity
    1000 (990 normal + 10 guests)
  • Connection
    Wired
  • Tamper alarm
    Yes
  • Brand
    VidiLine
  • Model
    VIDI-AC-2CS-P
  • SKU
    VIDI-AC-2CS-P
  • Product Type
    Access control keypad with card reader
  • Color
    Silver
  • Standby Power Consumption
    ≤30 mA
  • Keypad Type
    12 keys
  • Relay
    1 (NO, NC, COM)
  • Operating Power Consumption
    ≤120 mA
  • Card Type
    EM 125kHz
  • Read Range
    0~6 cm
  • PIN Length
    4~6 digits
  • Access Modes
    Card, PIN, Card+PIN
  • Relay Hold Time
    0~99 seconds (default 5)
  • Relay Load
    up to 2 A
  • Wiegand Output
    26-bit
  • Wiegand Input
    26/34-bit auto-detect
  • Indoor/Outdoor Use
    Indoor/Outdoor
