Автоматический выключатель Hager ADM440C RCBO, 4P, 6kA, B-40A, 30mA, Тип A

Автоматический выключатель Hager ADM440C RCBO, 4P, 6kA, B-40A, 30mA, Тип A

Hager
134,18 €
С НДС
Hager ADM440C RCBO, 4-pole, 6kA breaking capacity, B-curve 40A, 30mA Type A RCD. Reliable protection for your electrical installation.
Доставка: 5 рабочих дней
Поделиться

The Hager ADM440C is a combined residual current circuit breaker with overcurrent protection (RCBO), designed for 4-pole (4P) applications. It offers a rated current of 40A with a B tripping curve and a breaking capacity of 6kA, ensuring reliable protection against overloads and short circuits. The integrated residual current device (RCD) is type A, sensitive to 30mA, providing protection against earth faults and indirect contact.

  • 4-pole (4P) configuration for three-phase systems
  • Rated current 40A with B-curve for general lighting and socket circuits
  • Breaking capacity 6kA suitable for residential and commercial installations
  • 30mA Type A RCD for protection against sinusoidal and pulsating DC fault currents
  • Compact 4-module width for easy installation on DIN rail

Ideal for use in distribution boards where combined overcurrent and earth fault protection is required. Compiles with relevant standards for safety and performance.

  • Бренд
  • Код
    ADM440C
  • По наличию
    800 шт.
  • ean13
    3250611020264
  • MPN
    ADM440C

  • Монтаж
    DIN rail 35mm
  • Число полюсов
    4P
  • Trip curve
  • Rcd type
    A
  • Бренд
    Hager
  • Артикул
    ADM440C
  • Тип товара
    RCBO
  • EAN
    3250611020264
  • Model / Reference
    ADM440C
  • Breaking Capacity (Icn)
    6 kA
  • Rated Current (In)
    40 A
  • Residual Current (IΔn)
    30 mA
  • Rated Voltage (Ue)
    230/400V V
  • Rated Frequency
    50/60 Hz
  • Width (DIN Modules)
    4 module
  • Tripping / Time Delay Class
    Instantaneous
